Tutorial 8 - Audio Capture Tool
GigaStudio 3.0 can capture any of its output master channels to disk for creating
master mixes, sub-mixes, and individual tracks. It has a very simple to use interface and
has many powerful options.
Be aware that the capture to disk function is not available in ReWire mode. If you
need to record the GigaStudio tracks while in ReWire mode, use the rendering function
of your DAW program instead of the Audio Capture Tool in GigaStudio. The GigaStudio
capture tool is an option for recording your Giga tracks if you do not have a way of re-
cording them otherwise.
The audio capture tool has its own dockable tool bar.
The capture tool bar can be hidden/shown be selecting the “Audio Capture
Toolbar”option in the View menu. There are options available for the behavior of the
capture tool in the Capture menu which you can specify with a mouse click.
Auto Number Files will automatically number the captured wave files sequentially as
they are recorded. This is handy when capturing multiple tracks at one time.
Synchronize to MIDI will transfer the control of MIDI real time messages Start and
Stop to the sequencer program.
Start will open the capture dialog. This is the same thing as clicking the audio cap-
ture tool record button.
Stop will end the capture recording process. This is the same thing as clicking the
stop button on the capture tool bar.
Once you have set your capture options, use the tool bar button shortcut
to open the Capture Tool click the capture button on the tool bar. This is a
round red button similar to any other recording application or device.
Before you begin a capture session, you must first arm at least one Output Master
channel pair in the DSP Station, otherwise you will be presented with this friendly re-
minder:
