Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
Revision January, 2008, Doc. Name: 2007PDD23000007 1-93
MKS CT150 Back to Table
A. HMI factory settings
Baud rate: 9600, 7, E, 1. (RS-232)
Controller Station number: 11.
Control area/status area: None / None.
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type Format
Word No. Bit No.
Data In Register Cn n: 0 ~ 25 N/A
Setup Register Cn n: 40 ~ 43 N/A
45 ~ 50
90 ~ 97
Error Count Err_CNT 0 N/A
LV Value LV_VAL 0 N/A
Printmark Error PRTMARK_ERR 0 N/A
Batch Counter BAT_CNT 0 N/A
Waste Counter WASTE_CNT 0 N/A
Line Speed LINE_SPD 0 N/A
Actual Cutting Length ACT_CUT_LEN 0 N/A
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
Reset RST N/A 0
Jog Trim+ JOGTRIM_INC N/A 0
Jog Trim- JOGTRIM_DEC N/A 0
Read PI READ_PI N/A 0
Activate Data ACT_DATA N/A 0
Store Eeprom STR_EEPROM N/A 0
Start/Stop START_STOP N/A 0
Reset Mark Counter RSTMARK_CNT N/A 0
