Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-134 Revision January, 2008, Doc. Name: 2007PDD23000007
YOKOGAWA ACE PLC Back to Table
A. HMI factory settings
Baud rate: 9600, 8, EVEN, 1. (ASCII code)
Controller station number: 1.
CPU NO. : 1.
Control area/status area: D1 / D10.
NOTE
1) CheckSum and End character (CR, LF) are not used during communication. Therefore, the controller
should be set to “Not using CheckSum and End character”.
2) CPU number is used during communication, however, Screen Editor software does not have this
selection. Therefore, if the user desires to set CPU number, please set HMI station number in “General”
tab in the ”Configuration” dialog box in “Options” menu (Options Æ ”Configuration” Æ General). (HMI
station number is regarded as CPU number. The default setting of HMI station number is 0, but 0 is an
illegal number, the user must set it as a legal value.
B. Definition of controller Read/Write address
Registers
Register Type Format Word No. Data Size
WORD_DEVICE_X Xn n: 201 ~ 65464 Word
WORD_DEVICE_Y Yn n: 201 ~ 65464 Word
WORD_DEVICE_I In n: 1 ~ 16384 Word
WORD_DEVICE_E En n: 1 ~ 4096 Word
WORD_DEVICE_L Ln n: 1 ~ 65488 Word
WORD_DEVICE_M Mn n: 1 ~ 9984 Word
WORD_DEVICE_TP TPn n: 1 ~ 3072 Word
WORD_DEVICE_CP CPn n: 1 ~ 3072 Word
WORD_DEVICE_D Dn n: 1 ~ 8192 Word
WORD_DEVICE_B Bn n: 1 ~ 32768 Word
WORD_DEVICE_W Wn n: 1 ~ 65499 Word
WORD_DEVICE_Z Zn n: 1 ~ 512 Word
WORD_DEVICE_V Vn n: 1 ~ 64 Word
WORD_DEVICE_R Rn n: 1 ~ 4096 Word
WORD_DEVICE_TS TSn n: 1 ~ 3072 Word
WORD_DEVICE_CS CSn n: 1 ~ 3072 Word
¾ WORD_DEVICE_X / WORD_DEVICE_Y: The last two digits of address must be 1 or the multiple of
16+1 and less than 65.
