Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-36 Revision January, 2008, Doc. Name: 2007PDD23000007
Hitachi EH Series PLC Back to Table
A. HMI factory settings
Baud rate: 19200, 7, EVEN, 1.
Controller station number: 0.
Control area/status area: WR0 / WR10.
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type Format
Word No. Bit No.
Data Length
External Input WX WXrusn Word
External Output WY WYrusn
s: 0-A n: 0-7
r: 0-4
u: 0-4
N/A
Word
Internal Output WR WRn n: 0-C3FF N/A Word
Special Internal Output WR WRn n: F000-F1FF N/A Word
Shared Internal Output WM WMn n: 0-3FF N/A Word
CPU Link Area 1 WL WLn n: 0-3FF N/A Word
CPU Link Area 2 WL WLn n: 1000-13FF N/A Word
Timer/Counter TC TCn n: 0-511 N/A Word
Contacts
Read/Write Range
Register Type Format
Word No. Bit No.
External Input X Xrusb
External Output Y Yrusb
s: 0-A N/A
r: 0-4
u: 0-4
b: 0-95
Internal Output R Rb N/A b: 0-7FF
Shared Internal Output M Mnb n: 0-3FF b: 0-F
CPU Link Area 1 L Lnb n: 0-3FF b: 0-F
CPU Link Area 2 L Lnb n: 1000-13FF b: 0-F
On Delay Timer TD TDb N/A b: 0-255
Single-shot Timer SS SSb N/A b: 0-255
Up Counter CU CUb N/A b: 0-511
Up-down Counter up input CTU CTUb N/A b: 0-511
Up-down Counter down input CTD CTDb N/A b: 0-511
Up-down Counter down output CT CTb N/A b: 0-511
Progress Value Clear CL CLb N/A b: 0-511
Rising Edge Detection DIF DIFb N/A b: 0-511
Falling Edge Detection DFN DFNb N/A b: 0-511
