Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-8 Revision January, 2008, Doc. Name: 2007PDD23000007
Read/Write Range
Register Type Format
Word No. Bit No.
Data Length
Output Registers RW-n n: 0 ~ FFFFh N/A Word
Input Registers R-n n: 0 ~ FFFFh N/A Word
Output Registers Wn n: 40001 ~ 50000 N/A Word
Input Registers Wn n: 30001 ~ 40000 N/A Word
NOTE
1) The above addresses of Servo, AC drive, Temperature controller and PLC Module are in hexadecimal
format. PLC Word Device X and Y are in octal format. Other PLC Word Device M, S, T, C, D and HC are
in decimal format.
2) WORD_DEVICE_ X / WORD_DEVICE_Y / WORD_DEVICE_M / WORD_DEVICE_S: Address must be
0 or the multiple of 16.
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
Servo communication address SERVO-n.b n: 0 ~ 0700h b: 0 ~ f
AC drive communication address INVERTER-n.b n: 0 ~ 2299h b: 0 ~ f
TCntrl communication address TEMP_CTRL-n.b n: 0 ~ 6000h b: 0 ~ f
Servo Digital Input SERVO_DI-n N/A n: 1 ~ 8
Servo Digital Output SERVO_DO-n N/A n: 1 ~ 5
WORD_DEVICE_X PLC_Xn N/A n: 0 ~ 377(octal)
WORD_DEVICE_Y PLC_Yn N/A n: 0 ~ 377(octal)
WORD_DEVICE_M PLC_Mn N/A n: 0 ~ 1535
1536 ~ 4095
WORD_DEVICE_S PLC_Sn N/A n: 0 ~ 1023
WORD_DEVICE_T PLC_Tn N/A n: 0 ~ 255
WORD_DEVICE_C PLC_Cn N/A n: 0 ~ 255
TCntrl Bit communication address TEMP_CTRLB-n N/A n: 800 ~ 8FFh
Discrete Outputs RWB-n N/A n: 0 ~ FFFFh
Discrete Inputs RB-n N/A n: 0 ~ FFFFh
Discrete Outputs Bn N/A n: 1 ~ 10000
Discrete Inputs Bn N/A n: 10001 ~ 20000
NOTE
1) The above addresses of Servo, AC drive, Temperature controller and PLC Module are in hexadecimal
format.
