Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-82
Revision January, 2008, Doc. Name: 2007PDD23000007
Read/Write Range
Register Type
Format
Word No.
Bit No.
Data length
File Register
ZR-n
n: 0 ~ 32767
N/A
Word
Link Register
W-n
n: 0 ~ 1FFF
N/A
Word
Special Link Register
SW-n
n: 0 ~ 7FF
N/A
Word
¾
Xn, Yn, DXn, Bn, SBn, Wn, SWn : n is in hexadecimal.
Contacts
Read/Write Range
Contact type
Format
Word No.
Bit No.
Input
X-n
N/A
n: 0 ~ 1FFF
Output
Y-n
N/A
n: 0 ~ 1FFF
Direct input
DX-n
N/A
n: 0 ~ 1FFF
Direct output
DY-n
N/A
n: 0 ~ 15
Latch Relay
L-n
N/A
n: 0 ~ 8191
Annunciator
F-n
N/A
n: 0 ~ 2047
Edge Relay
V-n
N/A
n: 0 ~ 2047
Step Relay
S-n
N/A
n: 0 ~ 8191
Link Relay
B-n
N/A
n: 0 ~ 1FFF
Special Link Relay
SB-n
N/A
n: 0 ~ 7FF
Internal Relay
M-n
N/A
n: 0 ~ 8191
Special Internal Relay
SM-n
N/A
n: 0 ~ 2047
Timer Contact
TS-n
N/A
n: 0 ~ 2047
Timer Coil
TC-n
N/A
n: 0 ~ 2047
Retentive timer Contact
SS-n
N/A
n: 0 ~ 2047
Retentive timer Coil
SC-n
N/A
n: 0 ~ 2047
Counter Contact
CS-n
N/A
n: 0 ~ 1023
Counter Coil
CC-n
N/A
n: 0 ~ 1023
¾
Xn, Yn, DXn, Bn, SBn : n is in hexadecimal.
