M2i slave – Delta Electronics Network Device DOP-A/AE/AS User Manual
Page 69
Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-68
Revision January, 2008, Doc. Name: 2007PDD23000007
M2i Slave
A. HMI factory settings
Baud rate: 38400, 8, None, 1.
Controller station number: 1 (no function)
Control area/status area: SB0 / SB10.
NOTE
1) HMI station number is Slave station number. (default setting is 0)
2) The relation between M2i communication address and HMI internal registers.
Modbus address
Data definition in HMI
SB0000 ~ SB7FFF
$0 ~ $32767
SB8000 ~ SB83FF
$M0 ~ $M1023
SB8400
RCPNO
SB8500 ~ SBFFFF
RCP0 ~ RCP31487
B. Definition of controller Read/Write address
Registers
Register Type
Format
Word No.
Bit No.
Data Size
Word Address
SBn
n: 0000 ~ FFFF
N/A
Word
Contacts
Read/Write Range
Contact type
Format
Word No.
Bit No.
Bit Address
SBn.b
n:0000 ~ FFFF
b: 0 ~ F
C. Connections (Connector Pinouts):
Please refer to 1.1 Pin Definition of Serial Communication for detail.
