background image

Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series

Revision January, 2008, Doc. Name: 2007PDD23000007

1-65

LIYAN LYPLC EX

Back to Table

A. HMI factory settings

Baud rate: 9600, 7, EVEN, 1.

Controller station number: 0.

Control area/status area: D0 / D10.

B. Definition of controller Read/Write address

Registers

Read/Write Range

Register Type

Format

Word No.

Bit No.

Data length

Auxiliary Relay

Mn

n: 0 ~ 3064

N/A

Byte

Special Auxiliary Relay

Mn

n: 8000 ~ 8248

N/A

Byte

Status Relay

Sn

n: 0 ~ 992

N/A

Byte

Input Relay

Xn

n: 0 ~ 360(octal) N/A

Byte

Output Relay

Yn

n: 0 ~ 360(octal)

N/A

Byte

Timer PV

Tn

n: 0 ~ 255

N/A

Word

16-bit Counter PV

Cn

n: 0 ~ 199

N/A

Word

32-bit Counter PV

Cn

n: 200 ~ 255

N/A

Double Word

Data Register

Dn

n: 0 ~ 7999

N/A

Word

Special Data Register

Dn

n: 8000 ~ 8255

N/A

Word

Auxiliary Relay / Special Auxiliary Relay / Status Relay / Input Relay / Output Relay: Address must be the

multiple of 8.

Contacts

Read/Write Range

Contact type

Format

Word No.

Bit No.

Auxiliary Relay

Mn

N/A

n: 0 ~ 3071

Special Auxiliary Relay

Mn

N/A

n: 8000 ~ 8255

Status Relay

Sn

N/A

n: 0 ~ 999

Input Relay

Xn

N/A

n: 0 ~ 377(octal)

Output Relay

Yn

N/A

n: 0 ~ 377(octal)

Timer Flag

Tn

N/A

n: 0 ~ 255

Counter Flag

Cn

N/A

n: 0 ~ 255
