Taian TP02 PLC Back to Table
A. HMI factory settings
Baud rate: 19200, 7, None, 1.
Controller station number: 1.
Control area/status area: V1 / V10.
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type Format
Word No. Bit No.
Data length
WORD_DEVICE_X Xn n: 1 ~ 384 N/A Word
WORD_DEVICE_Y Yn n: 1 ~ 384 N/A Word
WORD_DEVICE_C Cn n: 1 ~ 2048 N/A Word
WORD_DEVICE_V Vn n: 1 ~ 1024 N/A Word
WORD_DEVICE_D Dn n: 1 ~ 2048 N/A Word
WORD_DEVICE_WS WSn n: 1 ~ 128 N/A Word
WORD_DEVICE_WC WCn n: 1 ~ 912 N/A Word
¾ WORD_DEVICE_X / WORD_DEVICE_Y / WORD_DEVICE_C: Address must be 1 or the multiple of
16+1.
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
BIT_DEVICE_X Xn N/A n: 1 ~ 384
BIT_DEVICE_Y Yn N/A n: 1 ~ 384
BIT_DEVICE_C Cn N/A n: 1 ~ 2048
BIT_DEVICE_SC SCn N/A n: 1 ~ 128
¾ BIT_DEVICE_SC: Only 1 Bit can be transferred for each read command.
