Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
Revision January, 2008, Doc. Name: 2007PDD23000007 1-63
LG XGT CNET Back to Table
A. HMI factory settings
Baud rate: 9600, 8, None, 1.
Controller station number: 0.
Control area/status area: DW0 / DW10.
NOTE
1) HMI default setting is predefined for XGL-CH2A CNET communication module.
B. Definition of controller Read/Write address
Registers
Register Type Format Word No. Bit No. Data Size
I/O Relay PWn n: 0 ~ 2047 N/A Word
Auxiliary Relay MWn n: 0 ~ 2047 N/A Word
Keep Relay KWn n: 0 ~ 2047 N/A Word
Link Relay LWn n: 0 ~ 11263 N/A Word
Special Relay FWn n: 0 ~ 2047 N/A Word (Read Only)
Timer Elapsed Value TWn n: 0 ~ 2047 N/A Word
Counter Elapsed Value CWn n: 0 ~ 2047 N/A Word
Data Register DWn n: 0 ~ 32767 N/A Word
Contacts
Contact type Format Word No. Bit No.
I/O Relay PXnb n: 0 ~ 2047 b: 0 ~ F
Auxiliary Relay MXnb n: 0 ~ 2047 b: 0 ~ F
Keep Relay KXnb n: 0 ~ 2047 b: 0 ~ F
Link Relay LXnb n: 0 ~ 11263 b: 0 ~ F
Special Relay FXnb n: 0 ~ 2047 b: 0 ~ F
Timer Contact Relay TXb N/A b: 0 ~ 2047
Counter Contact Relay CXb N/A b: 0 ~ 2047
Data Relay DXn.b n: 0 ~ 32767 b: 0 ~ F
