Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
Revision January, 2008, Doc. Name: 2007PDD23000007
1-39
HUST CNC Controller
A. HMI factory settings
Baud rate: 9600, 7, EVEN, 2.
Controller station number: 0.
Control area/status area: W0 / W10.
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type
Format
Word No.
Bit No.
Data Length
Word Register
Wn
n: 0 ~ 13500
N/A
Word
Double Word Register Dn
n: 0 ~ 13500
N/A
Double Word
NOTE
1) The unit for Hust CNC controller is D Word and Wn is the low word of Dn.
Contacts
Read/Write range
Contact Type
Format
Word No.
Bit No.
BIT_DEVICE_B
Bm.n
m: 0 ~ 13500
n: 0 ~ 31
BIT_DEVICE_I
In
N/A
n: 0 ~ 255 (8 DW)
BIT_DEVICE_O
On
N/A
n: 0 ~ 255 (8 DW)
BIT_DEVICE_C
Cn
N/A
n: 0 ~ 255 (8 DW)
BIT_DEVICE_S
Sn
N/A
n: 0 ~ 255 (8 DW)
BIT_DEVICE_A
An
N/A
n: 0 ~ 1023 (32 DW)
C. Connections (Connector Pinouts)
RS-232
DOP Series
9 pin D-SUB male (RS-232)
Controller
9 pin D-SUB male (RS-232)
Controller
9 pin D-SUB male
(RS-232)
RXD (2)
(2) TXD
TXD (3)
GND (5)
(3) RXD
(5) SG
(8) RTS
(7) CTS
Top View
Pin1
