Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
Revision January, 2008, Doc. Name: 2007PDD23000007 1-67
M2i Master Back to Table
A. HMI factory settings
Baud rate: 38400, 8, None, 1.
Controller station number: 1.
Control area/status area: SB0 / SB10.
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type Format
Word No. Bit No.
Data length
Word Address SBn n: 0000 ~ FFFF N/A Word
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
Bit Address SBn.b n: 0000 ~ FFFF b: 0 ~ F
