Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series

Revision January, 2008, Doc. Name: 2007PDD23000007

1-47

Koyo SU/DL Series

Back to Table

A. HMI factory settings

Baud rate: 9600, 8, ODD, 1 (RS-232).

Controller station number: 1.

Control area/status area: V1400 / V1410.

B. Definition of controller Read/Write address

Registers

Read/Write Range

Register Type

Format

Word No.

Bit No.

Data

Length

Timer Accumulated

Vn

n:

0 ~ 177 (octal)

N/A

Word

Counter Accumulated

Vn

n:

1000 ~ 1177 (octal)

N/A

Word

V Memory

Vn

n:

1400 ~ 7777 (octal)

N/A

Word

Linker Relays

Vn

n:

40000 ~ 40037 (octal)

N/A

Word

Input Status

Vn

n:

40400 ~ 40423 (octal)

N/A

Word

Output Status

Vn

n:

40500 ~ 40523 (octal)

N/A

Word

Control Relays

Vn

n:

40600 ~ 40635 (octal)

N/A

Word

Stage

Vn

n:

41000 ~ 41027 (octal)

N/A

Word

Timer Status

Vn

n:

41100 ~ 41107 (octal)

N/A

Word

Counter Status

Vn

n:

41140 ~ 41147 (octal)

N/A

Word

Spec. Relay 1

Vn

n:

41200 ~ 41205 (octal)

N/A

Word

Spec. Relay 2

Vn

n:

41216 ~ 41230 (octal)

N/A

Word

Contacts

Read/Write Range

Contact type

Format

Word No.

Bit No.

Linker Relays

GXn

N/A

n:

0 ~ 777 (octal)

Input Status

Xn

N/A

n:

0 ~ 477 (octal)

Output Status

Yn

N/A

n:

0 ~ 477 (octal)

Control Relays

Cn

N/A

n:

0 ~ 737 (octal)

Stage

Sn

N/A

n:

0 ~ 577 (octal)

Timer Status

Tn

N/A

n:

0 ~ 177 (octal)

Counter Status

CTn

N/A

n:

0 ~ 177 (octal)

Spec. Relay 1

SPn

N/A

n:

0 ~ 137 (octal)

Spec. Relay 2

SPn

N/A

n:

320 ~ 617 (octal)
