Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-12 Revision January, 2008, Doc. Name: 2007PDD23000007
Delta DVP PLC Back to Table
A. HMI factory settings
Baud rate: 9600, 7, Even, 1.
Controller station number: 1.
Control area/status area: D0 / D10.
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type Format
Word No. Bit No.
X_Data Xn n: 0 ~ 360(octal) N/A
Y_Data Yn n: 0 ~ 360(octal) N/A
M_Data Mn n: 0 ~ 1520, 1536 ~ 4080 N/A
S_Data Sn n: 0 ~ 1008 N/A
T_Register Tn n: 0 ~ 255 N/A
C_Register Cn n: 0 ~ 199 N/A
D_Register Dn n: 0 ~ 4095, 4096 ~ 9999 N/A
HC_Register Cn n: 200 ~ 255 N/A
NOTE
1) (W) is “Word”.
2) (DW) is “Double Word”.
3) X_Data / Y_Data / M_Data / S_Data: Address must be 0 or the multiple of 16.
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
X_Data Xn N/A n: 0 ~ 377(octal)
Y_Data Yn N/A n: 0 ~ 377(octal)
M_Data Mn N/A n: 0 ~ 1520, 1536 ~ 4080
S_Data Sn N/A n: 0 ~ 1023
T_Coil Tn N/A n: 0 ~ 255
C_Coil Cn N/A n: 0 ~ 255
