C. Connections (Connector Pinouts)
Delta Servo
RS-232
DOP Series
9 pin D-SUB male (RS-232)
Controller
CN3 cable connector (RS-232)
Controller
CN3 cable connector
(RS-232)
RXD (2) (2) TX
TXD (3)
GND (5)
(4) RX
(1) GND
1
2
3 5
4 6
Top View
RS-422
DOP Series
9 pin D-SUB male (RS-422)
Controller
CN3 cable connector (RS-422)
Controller
CN3 cable connector
(RS-422)
RXD+ (2) (5) TX+
RXD- (1)
TXD+ (3)
(6) TX-
(3) RX+
TXD- (4) (4) RX-
1
2
3 5
4 6
Top View
RS-485
DOP Series
9 pin D-SUB male (RS-485)
Controller
CN3 cable connector (RS-485)
Controller
CN3 cable connector
(RS-485)
RXD+ (2) (3) 485+
TXD+ (3)
RXD- (1)
(5) 485+
(4) 485-
TXD- (4) (6) 485-
1
2
3 5
4 6
Top View
