Keyence KV/KZ Series Back to Table
A. HMI factory settings
Baud rate: 9600, 8, EVEN, 1 (RS-232).
Controller station number: 0. (no PLC station number in protocol, therefore, only 1(HMI) to 1 (PLC)
communication is allowed.)
Control area/status area: DM-0 / DM-10.
NOTE
1) Please notice that no PLC station number in protocol, therefore, only 1(HMI) to 1 (PLC) communication
is allowed.
2) Only 1 Bit or 1 Word can be transferred for each communication. (Communication speed is slow.)
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type Format
Word No. Bit No.
Data Length
Timer T-nnn nnn: 0 ~ 199 N/A Word
Counter C-nnn nnn: 0 ~ 199 N/A Word
High-speed Counter CTH-n n: 0 ~ 1 N/A Word
High-speed Counter
Comparator
CTC-n n: 0 ~ 3 N/A Word
Data Memory DM-nnnn nnnn: 0 ~ 1999 N/A Word
Temporary Data Memory TM-nn nn: 0 ~ 31 N/A Word
Timer Preset Value PT-nnn nnn: 0 ~ 199 N/A Word
Counter Preset Value PC-nnn nnn: 0 ~ 199 N/A Word
CTC Preset Value PCTC-n n: 0 ~ 3 N/A Word
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
Relay R-nnnbb nnn: 0 ~ 69 bb: 00 ~ 15
Timer T-nnn N/A nnn: 0 ~ 199
Counter C-nnn N/A nnn: 0 ~ 199
High-speed counter
comparator
CTC-n N/A n: 0 ~ 3
