Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-116 Revision January, 2008, Doc. Name: 2007PDD23000007
Omron CJ1/CS1 Series PLC Back to Table
A. HMI factory settings
Baud rate: 9600, 7, EVEN, 2. (RS-232)
Controller station number: 0.
Control area/status area: D0 / D10.
¾
This driver can support OMRON CS/CJ/CP1/CQM/CV/CVM series PLC simultaneously.
NOTE
The meaning of Communication Error Message:
1) Word Device:
The Device Name and Address Value will display. For example, if using CIO, H, A, D, E, T, C, W, EM, IR,
DR, TK, it will show CIOn, Hn, An, Dn, Em.n, Tn, Cn, Wn, EMn, IRn, DRn, TKn respectively. “n” is the
Address Value.
2) Bit Device:
The Device Name and Word Address Value will display, but the Bit Address Value will not. For example,
if using CIO, H, A, D, E, T, C, W, EM, IR, DR, TK, it will show CIOBn, HBn, ABn, DBn, EBm.n, TBn, CBn,
WBn, EMBn, IRBn, DRBn, TKBn respectively. “n” is the Word Address Value.
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type Format
Word No. Bit No.
Data length
CIO area CIOn n: 0 ~ 9999 N/A Word
Hold area Hn n: 0 ~ 999 N/A Word
Auxiliary area An n: 0 ~ 999 N/A Word
DM area Dn n: 0 ~ 65535 N/A Word
EM area Em.n M: 0 ~ 12 (bank no.)
n: 0 ~ 65535
N/A Word
Timer PVs Tn n: 0 ~ 9999 N/A Word
Counter PVs Cn n: 0 ~ 9999 N/A Word
Work area Wn n: 0 ~ 999 N/A Word
EM Current Bank area EMn n: 0 ~ 65535 N/A Word
Index Register IRn n: 0 ~ 99 N/A Double Word
DR area DRn n: 0 ~ 99 N/A Word
TK area TKn n: 0 ~ 1022 (Even
No.)
N/A
Byte
