Modicon TSX Micro (Uni-Telway) Back to Table
A. HMI factory settings
Baud rate: 9600, 8, ODD, 1.
Controller station number: 2.
Control area/status area: %MW0 / %MW10.
NOTE
1) HMI station needs to be adjusted to 1 ~ 8.
2) PLC station and HMI station can be the same.
3) The internal memory and relative parameters in PLC should be set properly first. Otherwise, it cannot
communicate except %S.
B. Definition of controller Read/Write address
Registers
Register Type Format Word No. Bit No. Data Size
WORD_DEVICE_ Internal %MWn n: 0 ~ 65534 N/A Word
WORD_DEVICE_ System %SWn n: 0 ~ 127 N/A Word
WORD_DEVICE_ Input %KWn n: 0 ~ 65534 N/A Word
¾ %KWn is “read only”.
Contacts
Contact type Format Word No. Bit No.
BIT_DEVICE_ Internal %Mn:b n:0 ~ 65534 b:0 ~ 15
BIT_DEVICE_ System %Sn - n:0 ~ 127
BIT_DEVICE_ Internal1 %Mn - n:0 ~ 65534
¾ %Mn: b is Bit address that corresponds to WORD_DEVICE_ Internal (%MWn).
¾ %Mn is PLC internal relay address.
¾ The read/write range of WORD_DEVICE_ Internal / BIT_DEVICE_ Internal depends on PLC used
memory.
