Koyo K-Sequence Back to Table
A. HMI factory settings
Baud rate: 9600, 8, ODD, 1 (RS-232).
Controller station number: 1.
Control area/status area: R1400 / R1420.
NOTE
1) If read / write address exceeds the valid range, HMI will stop read/write operation and show “….Error
6….. Command Can Not be Executed….” on the screen.
B. Definition of controller Read/Write address
Registers
Read/Write Range
Register Type Format
Word No. Bit No.
Data
Length
Input Status Xnnnn nnnn: 0 ~ 1760 (octal) N/A Word
Output Status Ynnnn nnnn: 0 ~ 1760 (octal) N/A Word
Link Relays GXnnnn nnnn: 0 ~ 3760 (octal) N/A Word
Relays GQnnnn nnnn: 0 ~ 3760 (octal) N/A Word
Relays Mnnnn nnnn: 0 ~ 3760 (octal) N/A Word
Stage Snnnn nnnn: 0 ~ 1760 (octal) N/A Word
Timer Status Tnnn nnn: 0 ~ 360 (octal) N/A Word
Control Relays Cnnn nnn: 0 ~ 360 (octal) N/A Word
Special Relay 1 SPnnn nnn: 0 ~ 760 (octal) N/A Word
Register Rnnnnn nnnnn: 0 ~ 41237 (octal) N/A Word
Register Pnnnnn nnnnn: 0 ~ 37777 (octal) N/A Word
¾ nnnn: Is in octal format and must be the multiple of 16 except for R and P.
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
Input Status Xnnnn N/A nnnn: 0 ~ 1777 (octal)
Output Status Ynnnn N/A nnnn: 0 ~ 1777 (octal)
Linker Relays GXnnnn N/A nnnn: 0 ~ 3777 (octal)
Relays GQnnnn N/A nnnn: 0 ~ 3777 (octal)
Control Relays Mnnnn N/A nnnn: 0 ~ 3777 (octal)
Stage Snnnn N/A nnnn: 0 ~ 1777 (octal)
Timer Status Tnnn N/A nnn: 0 ~ 377 (octal)
