Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-18 Revision January, 2008, Doc. Name: 2007PDD23000007
Read/Write Range
Word No. Bit No.
Low Byte High Byte
Register Type Format
Element No.
Slot or File No.
Counter Accumulator Value Cf:n.ACC n: 0 ~ 255 N/A f: 10 ~ 255
If f is ignored, file no. will be
default setting 5.
Control File Rf:n n: 0 ~ 255 N/A f: 10 ~ 255
If f is ignored, file no. will be
default setting 6.
Control Size of Bit Array Rf:n.LEN n: 0 ~ 255 N/A f: 10 ~ 255
If f is ignored, file no. will be
default setting 6.
Control Reserved File Rf:n.POS n: 0 ~ 255 N/A f: 10 ~ 255
If f is ignored, file no. will be
default setting 6.
Integer File Nf:n n: 0 ~ 255 N/A f: 10 ~ 255
If f is ignored, file no. will be
default setting 7.
¾ Bit No : Low byte is not used, so the value is 0. High byte stores file number.
Contacts
Read/Write Range
Word No. Bit No.
Low Byte High Byte
Contact Type Format
Element No.
Bits Slot or File No.
Output O:n/b
O:s.n/b
n: 0 ~ 30 b: 0 ~ 15 Slot No. s = 0
s: 0 ~ 255
File No. = 0
Input I:n/b
I:s.n/b
n: 0 ~ 30 b: 0 ~ 15 Slot No.
s = 0
s: 0 ~ 255
File No. = 1
Status S2:n/b n: 0 ~ 31 b: 0 ~ 15 2
Bit Bf:n/b n: 0 ~ 255 b: 0 ~ 15 f: 10 ~ 255
If f is ignored, file no. will be
default setting 3.
Timer Tf:n/b n: 0 ~ 255 b: 0 ~ 15
Tf:n/EN n: 0 ~ 255 15
Tf:n/TT n: 0 ~ 255 14
Tf:n/DN n: 0 ~ 255 13
f: 10 ~ 255
If f is ignored, file no. will be
default setting 4.
Timer Preset Value Tf:n.PRE/b n: 0 ~ 255 b: 0 ~ 15 f: 10 ~ 255
If f is ignored, file no. will be
default setting 4.
