Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
Revision January, 2008, Doc. Name: 2007PDD23000007 1-77
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
Input Xn N/A n: 0 ~ 7FF
Output Yn N/A n: 0 ~ 7FF
Link Relay Bn N/A n: 0 ~ FFF
Internal Relay Mn N/A n: 0 ~ 8191
Special Internal Relay SMn N/A n: 9000 ~ 9255
Latch Relay Ln N/A n: 0 ~ 2047
Annunciator Fn N/A n: 0 ~ 2047
Timer Contact TSn N/A n: 0 ~ 999
Timer Coil TCn N/A n: 0 ~ 999
Counter Contact CSn N/A n: 0 ~ 999
Counter Coil CCn N/A n: 0 ~ 999
C. Connections (Connector Pinouts)
RS-422
DOP
9 pin D-SUB male (RS-422)
Controller
Cable Connector (RS-422)
RXD+ (2) SDA
RXD- (1)
TXD+ (3)
SDB
RDA
TXD- (4) RDB
