Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series

Revision January, 2008, Doc. Name: 2007PDD23000007

1-123

Read/Write Range

Register Type

Format

Word No.

Bit No.

Output Image

QWn

n: 0 ~ 65534

N/A

Output Image

QDn

n: 0 ~ 65532

N/A

Internal Bits

MWn

n: 0 ~ 65534

N/A

Internal Bits

MDn

n: 0 ~ 65532

N/A

Data Area

DBm.DBWn

n: 0 ~ 65534

m: 1 ~ 255

DBm.DBDn

n: 0 ~ 65532

m: 1 ~ 255

Data Area (DB10)

DBWn

n: 0 ~ 65534

N/A

DBDn

n: 0 ~ 65532

N/A

VWn

n: 0 ~ 65534

N/A

VDn

n: 0 ~ 65532

N/A

Timer

Tn n:

0-65535

N/A

Counter

Cn n:

0-65535

N/A

NOTE

1) The valid digit number of the value for the T(Timer) and C(Counter) is 3-digits only. Therefore, please

enter a 3-digit number. If entering a number that exceeds 3 digits, only the first 3 digits are valid (decimal

format). The other digits of the value for the T(Timer) will be replaced as 0 and the other digits of the

value for the C(Counter) will be abandoned. For example, assume that the users enter the value “12345”,

the actual write value for the T(Timer) will be “12300” and the actual write value for the C(Counter) will be

“123”.

Contacts

Read/Write Range

Contact type

Format

Word No.

Bit No.

Input Image

In.b

n: 0 ~ 65535

b: 0 ~ 7

Output Image

Qn.b

n: 0 ~ 65535

b: 0 ~ 7

Internal Bit

Mn.b

n: 0 ~ 65535

b: 0 ~ 7

Data Area Bit

DBm.DBXn.b

n: 0 ~ 65535

b: 0 ~ 7

m = 1 ~ 255

Data Area Bit (10 DB)

DBXn.b

n: 0 ~ 65535

b: 0 ~ 7

Vn.b

n: 0 ~ 65535

b: 0 ~ 7

NOTE

1) For all contacts when performing “Multiple Duplicate” function:

y

If it exceeds 65535 when increasing, it will be regarded as 0.

y

If it is less than 0, it will be regarded as 655XX.
