Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-32 Revision January, 2008, Doc. Name: 2007PDD23000007
Festo PLC Back to Table
A. HMI factory settings
Baud rate: 9600, 8, None, 1.
Controller Station number: 0. (no PLC station number in protocol)
Control area/status area: R0 / R10.
NOTE
1) Connectable PLC: FEC-FC Model
B. Definition of controller Read/Write address
Registers
Register Type Format Word No. Bit No. Data Size
WORD_DEVICE_IW Iwn n: 0 ~ 255 N/A Word
WORD_DEVICE_OW Own n: 0 ~ 255 N/A Word
WORD_DEVICE_FW FWn n: 0 ~ 9999 N/A Word
WORD_DEVICE_TW TWn n: 0 ~ 255 N/A Word
WORD_DEVICE_CW CWn n: 0 ~ 255 N/A Word
WORD_DEVICE_R Rn n: 0 ~ 255 N/A Word
WORD_DEVICE_TP TPn n: 0 ~ 255 N/A Word
WORD_DEVICE_CP CPn n: 0 ~ 255 N/A Word
Contacts
Register Type Format Word No. Bit No.
BIT_DEVICE_I In.b n: 0 ~ 255 b: 0 ~ 15
BIT_DEVICE_O On.b n: 0 ~ 255 b: 0 ~ 15
BIT_DEVICE_F Fn.b n: 0 ~ 9999 b: 0 ~ 15
BIT_DEVICE_T Tn N/A n: 0 ~ 255
BIT_DEVICE_C Cn N/A n: 0 ~ 255
BIT_DEVICE_TON TONn N/A n: 0 ~ 255
BIT_DEVICE_TOFF TOFFn N/A n: 0 ~ 255
¾ BIT_DEVICE_T / BIT_DEVICE_C / BIT_DEVICE_TON / BIT_DEVICE_TOFF: Only 1 Bit can be
transferred for each communication.
¾ Only 1 Bit or 1 Word can be transferred for each write command.
