Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
1-26 Revision January, 2008, Doc. Name: 2007PDD23000007
Contacts
Read/Write Range
Word No. Bit No.
Low Byte High Byte
Contact Type Format
Element No.
Bits Index No.
Parameter Pn:I.b n: 0 ~ 999 b: 0 ~ 31 I: 0 ~ 31
¾ Bit No : Low byte stores Bit address. High byte stores index number.
C. Connections (Connector Pinouts)
RS-485
DOP Series
9 pin D-SUB male (RS-485)
Controller
RS-485 cable connector
R XD + (2) 68 TXD /R XD +
TXD+ (3 )
R XD - (1 )
TXD- (4)
Shell Shell
69 TXD /R XD -
Explanation of Control Word & Status Word
Control Word
Bit Bit = 0 Bit = 1
15 No Function Reversing
14 Choice of Setup 2 (msb)
13 Choice of Setup 1 (lsb)
12 No Function Relay 04 activated
11 No Function Relay 01 activated
10 Data Not Vaild Vaild
9 Ramp 1 Ramp2
8 Jog 1 OFF ON
7 No Function Reset
6 Ramp Stop Start
5 Hold Ramp Enable
4 Quick-Stop Ramp
3 Coasting Enable
2 DC Brake Ramp
1 Preset reference choice msb
0 Preset reference choice msb
¾ When Bit 10 = 1 (Data Valid), the Control Word is valid.
