Read/Write Range
Word No. Bit No.
Low Byte High Byte
Contact Type Format
Element No.
Bits Slot or File No.
Timer Accumulator Value Tf:n.ACC/b n: 0 ~ 255 b: 0 ~ 15 f: 10 ~ 255
If f is ignored, file no. will be
default setting 4.
Counter Flag Cf:n/b n: 0 ~ 255 b: 0 ~ 15
Cf:n/CU n: 0 ~ 255 15
Cf:n/CD n: 0 ~ 255 14
Cf:n/DN n: 0 ~ 255 13
Cf:n/OV n: 0 ~ 255 12
Cf:n/UN n: 0 ~ 255 11
Cf:n/UA n: 0 ~ 255 10
f: 10 ~ 255
If f is ignored, file no. will be
default setting 5.
Counter Preset Value Cf:n.PRE/b n: 0 ~ 255 b: 0 ~ 15 f: 10 ~ 255
If f is ignored, file no. will be
default setting 5.
Counter Accumulator Value Cf:n.ACC/b n: 0 ~ 255 b: 0 ~ 15 f: 10 ~ 255
If f is ignored, file no. will be
default setting 5.
Control Rf:n/b n: 0 ~ 255 b: 0 ~ 15
Rf:n/EN n: 0 ~ 255 15
Rf:n/DN n: 0 ~ 255 13
Rf:n/ER n: 0 ~ 255 11
Rf:n/UL n: 0 ~ 255 10
Rf:n/IN n: 0 ~ 255 9
Rf:n/FD n: 0 ~ 255 8
f: 10 ~ 255
If f is ignored, file no. will be
default setting 6.
Control Size of Bit Array Rf:n.LEN/b n: 0 ~ 255 b: 0 ~ 15 f: 10 ~ 255
If f is ignored, file no. will be
default setting 6.
Control Reserved Rf:n.POS/b n: 0 ~ 255 b: 0 ~ 15 f: 10 ~ 255
If f is ignored, file no. will be
default setting 6.
Integer Nf:n/b n: 0 ~ 255 b: 0 ~ 15 f: 10 ~ 255
If f is ignored, file no. will be
default setting 7.
¾ Bit No : Low byte stores Bit address. High byte stores file number.
NOTE
1) Device O and I need to assign Slot No. (s). If not assign Slot No., it will use default setting 0.
