Delta Electronics Network Device DOP-A/AE/AS User Manual
Page 76
Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
Revision January, 2008, Doc. Name: 2007PDD23000007
1-75
C. Connections (Connector Pinouts)
RS-422
DOP Series
9 pin D-SUB male (RS-422)
Controller
8pin Mini DIN male (RS-422)
Controller
8pin Mini DIN male
(RS-422)
RXD+ (2)
(7) TXD+
RXD- (1)
TXD+ (3)
(4) TXD-
(2) RXD+
TXD- (4)
(1) RXD-
GND (5)
(3) SG
Top View
1
4
7
2
3
