¾ CJ1M Models: An: A0-A477 is “read only”.
Contacts
Read/Write Range
Contact type Format
Word No. Bit No.
CIO area CIOBnbb n: 0 ~ 9999 bb: 00 ~ 15
Hold area HBnbb n: 0 ~ 999 bb: 00 ~ 15
Auxiliary area ABnbb n: 0 ~ 999 bb: 00 ~ 15
DM area DBnbb n: 0 ~ 65535 bb: 00 ~ 15
EM area EBm.nbb n: 0 ~ 65535
m: 0 ~ 12 (bank no.) bb: 00 ~ 15
Timer area TBn N/A n: 0 ~ 9999
Counter area CBn N/A n: 0 ~ 9999
Work area WBnbb n: 0 ~ 999 bb: 00 ~ 15
EM Current Bank area EMBnbb n: 0 ~ 65535 bb: 00 ~ 15
Index Register IRBnbb n: 0 ~ 99 bb: 00 ~ 31
DR area DRBnbb n: 0 ~ 99 bb: 00 ~ 15
TK area TKBnbb n: 0 ~ 1022 (Even
No.) bb: 00 ~ 15
NOTE
1) The following address cannot be written:
y IRn and DRn: It is not valid if the users write them. HMI will not show any error message if the write
operation is done.
y An and Abnbb: Some range of An and Abnbb (Auxiliary area) is “read only”.
y TKn / TKBnbb / TBn / CBn / EMBnbb / IRBnbb / DRBnbb: Writing these addresses is not allowed. If
the write operation is done, the error will occur and display the error message “Command Can Not
be Executed…” on the screen of HMI.
2) The unit of IR address is “Double Word”.
3) The unit of TK address is “Byte” and it should be even number.
