Delta Electronics Network Device DOP-A/AE/AS User Manual
Page 34
Delta DOP Series HMI Connection Manual|DOP-A/AE/AS Series
Revision January, 2008, Doc. Name: 2007PDD23000007
1-33
C. Connections
NOTE
1) Communication port of PLC: COM port
2) It needs to use the dedicated cable for FESTO controllers Æ Cable for transferring TTL to RS-232 and it
is 6 pin RJ-12 connector at PLC side.
