9424200994 Rev N 465
4 5.0 I2 0.50 A 1.798 sec 1.988 sec P / F
4 5.0 I2 2.50 A 0.944 sec 1.044 sec P / F
4 9.9 I2 0.20 A 8.300 sec 9.173 sec P / F
4 9.9 I2 0.50 A 3.535 sec 3.907 sec P / F
4 9.9 I2 2.50 A 1.844 sec 2.038 sec P / F
Timing Verification (IG Mode, SEF)
Time Dial Range = 0.0 to 9.9
Timing Accuracy =
±5% or ±1½ cycles, whichever is greater
Step Time Dial Time Curve Applied Current Low Actual Timing High Pass/Fail
4 0.5 I2 0.20 A 0.444 sec 0.491 sec P / F
4 0.5 I2 0.50 A 0.190 sec 0.240 sec P / F
4 0.5 I2 0.80 A 0.149 sec 0.197 sec P / F
4 5.0 I2 0.20 A 4.204 sec 4.647 sec P / F
4 5.0 I2 0.50 A 1.798 sec 1.988 sec P / F
4 5.0 I2 0.80 A 1.401 sec 1.548 sec P / F
4 9.9 I2 0.20 A 8.300 sec 9.173 sec P / F
4 9.9 I2 0.50 A 3.535 sec 3.907 sec P / F
4 9.9 I2 0.80 A 2.674 sec 3.111 sec P / F
BE1-11g Inverse Overcurrent (51) Test
