Swath XL
Software Version 3.00
3-29 Chapter 3 - Real-Time Guidance
Data Setup
As Applied
The As Applied menu item determines whether As Applied data is stored to the PC card during the real time guidance
process. If this is set to No, then no As Applied data is stored. If set to Yes then As Applied data is stored to the PC
card. As Applied data is not stored internally in the Smartpad. In order to properly store As Applied data, you must
have the PCMCIA data card installed in the Smartpad PC card slot during the real time guidance process. As Applied
data is written in real time to the PCMCIA card. You are prompted for an As Applied data file name when starting the
real-time guidance process.
To change the As Applied setting; highlight the As Applied menu item and press . The As Applied dialog box
appears. Select the desired setting using the arrow keys . Once the desired setting is selected, press to
return to the Data setup menu, see Figure 3-34.
Figure 3-34: The As Applied Menu Item
Setting Description
No No As Applied data is stored to the PC card.
Yes As Applied data is stored to a PC card inserted into the Smartpad PC card slot. You are
prompted for a file name when starting guidance.
Table 3-11: As Applied Settings
