TeeJet Swath XL - Manual (Page 33)

Swath XL
Software Version 3.00
2-13 Chapter 2 - Software Overview
Main Setup
Smartpad Setup
Smartpad Setup defines all parameters associated with the Smartpad. There are two Smartpad Setup menu items; Dis-
play Brightness and Display Backlight. Smartpad Setup default values are listed in Table 2-3.
To access the Smartpad menu page, highlight the Setup menu item in the Main menu page and press . This takes
you to the Setup menu page, see Figure 2-14 (right side). Within the Setup Menu, select the Smartpad menu item
using the arrow keys . Press to enter the Smartpad menu page. Once in the Smartpad menu page, you can
change any of the menu item settings by highlighting the desired menu item and pressing .
Figure 2-14: Accessing the Smartpad Menu Page
Setting Name Default Value
Change at 1st
Time Start Up
Display Brightness 7 Optional
Display Backlight On Optional
Table 2-3: Smartpad Menu Item Default Settings
