Chapter 2 - Software Overview 2-20
Communications Setup
Swath XL
Software Version 3.00
Port Data Bits
The Data Bits menu item sets the GPS port Data Bits on the Smartpad, see Table 2-9.
To change the Data Bits setting, highlight the Data Bits menu item and press . The Port Data Bits dialog box
appears. Select the desired setting using the arrow keys . Once the desired setting is selected, press to
return to the Communications setup menu, see Figure 2-21.
Figure 2-21: The Port Data Bit Menu Item
Setting Description
7 Sets the GPS serial port data bit value to 7.
8 Sets the GPS serial port data bit value to 8. This is the default setting.
Table 2-9: The Port Data Bit Menu Item Settings
