Ee figure 3-21, See figure 3-22 – TeeJet Swath XL User Manual
Page 66
Chapter 3 - Real-Time Guidance
3-18
Lightbar Setup
Swath XL
Software Version 3.00
Figure 3-21: Swath Display Mode
Figure 3-22: Vehicle Display Mode
Center LED stack equals current
guideline.
Moving LED represents the vehicle
position.
Moving LED represents the
current guideline.
Center LED stack represents
the vehicle.
