TeeJet Swath XL - Manual (Page 39)

Swath XL
Software Version 3.00
2-19 Chapter 2 - Software Overview
Communications Setup
Port Baud Rate
The Baud Rate menu item sets the GPS port baud rate on the Smartpad, see Table 2-8.
To change the Baud Rate setting, highlight the Baud Rate menu item and press . The Port Baud Rate dialog box
appears. Select the desired setting using the arrow keys . Once the desired setting is selected, press to
return to the Communications setup menu, see Figure 2-20.
Figure 2-20: The Port Baud Rate Menu Item
Setting Description
Auto Automatically determines the GPS port Baud Rate. This is the default setting.
1200 Sets the GPS serial port Baud Rate to 1200.
4800 Sets the GPS serial port Baud Rate to 4800.
9600 Sets the GPS serial port Baud Rate to 9600.
19200 Sets the GPS serial port Baud Rate to 19200.
Table 2-8: The Port Baud Rate Menu Item Settings
