TeeJet Swath XL - Manual (Page 140)

Chapter 4 - Waypoint Navigation 4-20
Lightbar Setup
Swath XL
Software Version 3.00
Display Message
Allows you to select a message you want to display on the lightbar. This message is preempted by point information.
To change the Display Message setting, highlight the Display Message menu item and press . The Display Mes-
sage dialog box appears. Select the desired message using the arrow keys . Once the desired message is
selected, press to return to the Lightbar setup menu, see Figure 4 -19.
Figure 4-19: Display Message Set to COG
Setting Description
Off No text is displayed for this message.
COG Displays the vehicle heading, Course on Ground (COG).
SOG Displays the vehicle Speed on Ground (SOG).
Table 4-9: Display Message Settings
