TeeJet Swath XL - Manual (Page 31)

Swath XL
Software Version 3.00
2-11 Chapter 2 - Software Overview
Main Setup
Unit
The Unit menu item defines the Swath XL measurement system. There are two choices; US and Metric. The unit set
in this menu field affects the entire Swath XL software suite.
To change the System Unit, highlight the Unit menu item and press . The System Unit dialog box appears. Select
the desired unit setting using the arrow keys . Once the desired unit is selected, press to return to the Sys-
tem setup menu, see Figure 2-12.
Figure 2-12: The Unit Menu Item
Setting Description
US All units are entered and displayed in Feet, Miles, Acres and US volumes. This is the
default setting.
Metric All units are entered and displayed in Meters, Kilometers, Hectare and Metric volumes.
Table 2-2: The Unit Menu Item Settings
