Swath XL

Software Version 3.00

4-9

Chapter 4 - Waypoint Navigation

Data Setup

Sample Number

The Sample # is a number assigned to each pulled sample. If this menu field is set to YES, each time a sample point
is added to the Point/Grid file, you are prompted by the program to enter a new sample number. If this menu field is
set to AUTO, you are not prompted each time a point is added and the numbering sequence automatically increments
by one for each sample pulled. You are prompted for a starting number after Start Nav 2 Point menu item has been
pressed. If this menu item is set to Off, then no sample number is added to any new sample points.

To change the Sample Number setting: highlight the Sample Number menu item and press

. The Sample Number

dialog box appears. Select the desired setting using the arrow keys

. Once the desired setting is selected, press

to return to the Data setup menu, see Figure 4 -8.

Figure 4-8: The Sample # Menu Field - Yes Item Selected

Setting

Description

Off

A sample number is not added to any new sample points.

Yes

You are prompted for a new sample number each time you mark a sample
point.

Auto

The sample number automatically increases by 1. You are prompted for a
starting number.

Table 4-4: Sample Number Settings
