Swath XL
Software Version 3.00
1-7 Chapter 1 - Introduction to Swath XL
System Specifications and Requirements
System Specifications and Requirements
Swath XL Lightbar
• ABS/Polycarbonate alloy construction,
• Dimensions: 16" W x 3" H x 3" D (405 mm x 76 mm x 76 mm),
• Weight: 8 oz. (.22 Kg.),
• Molded cables with weatherproof connectors,
• High-lumen red, yellow, and green LEDs,
• 8 character, high-intensity alpha-numeric LED display.
Smartpad Interface Cable
• 12V DC power required,
• Reverse polarity and high/low voltage protection,
• Status detection leads for boom master on/off,
• Additional cables lengths available for increased mounting options.
Swath XL Smartpad
• 1/4 CGA backlit display with adjustable contrast,
• Six key sealed membrane keypad,
• Internal alarm with volume control,
• Dimensions: 5.0" W x 9.0" H x 1.5" D (127 mm x 228 mm x 38 mm),
• Weight: 13 Oz. (0.37 Kg.),
• OS: Windows CE (Ver 2.0 or higher).
GPS Receiver Compatibility
The Swath XL product does not include a GPS receiver. Swath XL is compatible with any differentially cor-
rected, sub-meter GPS (D-GPS) receiver which outputs NMEA 0183 data at 2Hz or greater. MID-TECH
recommends the MID-TECH Rx-100p or Rx400p DGPS receiver for the Swath XL product.
Optional PCMCIA Flash Storage Card
• A 30+ MB, ATA Flash Storage Card.
Compatible card requirements and recommendations:
• Storage Size: 30 MB minimum,
• Drive Reader Compatibility: Complete PC Card Release 2.1 and ATA release 1.02,
