TeeJet Swath XL User Manual
Page 148
Chapter 4 - Waypoint Navigation
4-28
Nav 2 Point Real-Time Scenarios
Swath XL
Software Version 3.00
Figure 4 -29 shows the real-time icons that are included in the real-time view button bar area. This list of icons
changes based on how the setup process was configured.
Figure 4-28: Boundary Mapping in the Real-time View Page
Figure 4-29: Real-time Icons used in the Boundary Mapping Example
