Chapter 3 - Real-Time Guidance 3-66
Mapping Points and Hazards
Swath XL
Software Version 3.00
Marking a Named Hazard
The map object Named Hazard allows you to mark a hazard at the vehicle location. The map object Named Hazard
can be used later in Hazard Detection, page 3-67, to notify the operator of potentially hazardous objects or features
within the field. Hazard detection does not work with point objects. When Swath XL is setup to map a Named Haz-
ard, a Hazard button is added to the view page button bar, see Figure 3-90. To map a Named Hazard, drive to the loca-
tion of the object or feature you want to map. This location should coincide with the location of your GPS antenna.
Next, highlight the Hazard button in the button bar using the keys then press . Notice that when you high-
light the Hazard button, the name of the hazard appears in the information box at the bottom of the view page.
Figure 3-90: Mapping a Named Hazard
