Operating Instructions – MOVIMOT® MM03C - MM3XC
7
Startup with binary control (control via terminals)
Startup of Standard Design
Inverter response
according to the
terminal level
Legend
0 = No voltage
1 = Voltage
X = Any
Network
24 V
f1/f2
CW/Stop
CCW/Stop
Status LED
Inverter
behavior
0
0
x
x
x
Off
Inverter off
1
0
x
x
x
Off
Inverter off
0
1
x
x
x
Flashing
yellow
Stop, supply sys-
tem missing
1
1
x
0
0
Yellow
Stop
1
1
0
1
0
Green
Clockwise with f1
1
1
0
0
1
Green
Counterclock-
wise with f1
1
1
1
1
0
Green
Clockwise with f2
1
1
1
0
1
Green
Counterclock-
wise with f2
1
1
x
1
1
Yellow
Stop
0
0
