118
Operating Instructions – MOVIMOT® MM03C - MM3XC
9
Startup procedure
Startup with Communications Interface / Fieldbus
6. Place the MOVIMOT
®
inverter on the terminal box and secure it.
7. Set the required maximum speed using setpoint potentiometer f1.
8. Re-insert screw plug of setpoint potentiometer f1 with gasket.
9. Switch on the voltage.
05066BXX
[1] Pot. position
1 2 3 4 5 6 7 8 9 10 0
100
f [Hz
[1]
]
2
75
25
50
6 5
f
1
Information about the function in connection with RS-485 master can be found starting
on page 122.
Information about the function in connection with fieldbus interfaces can be found in the
corresponding manuals.
• PROFIBUS Interfaces, Field Distributors
• InterBus Interfaces, Field Distributors
• DeviceNet/CANopen Interfaces, Field Distributors
• AS-Interfaces, AS-i field distributors
0 0
