Operating Instructions – MOVIMOT® MM03C - MM3XC
47
6
Connection between MOVIMOT® and motor mounting close to the motor
Electrical Installation with Integrated AS-Interface
The ALA4 design results in the following connection options to the motor, dependent
upon the hybrid cable used:
Design B1 B2
MOVIMOT ® ALA4 ALA4
Motor Cable gland/terminals ASB4
Hybrid cables 0 817 948 4 0 816 208 5
Additional
Information page 50 page 50
51853AXX
[1] Connection via terminals
B1 B2
ASB4
[1]
ALA4
ALA4
