Unit designations (MOVIMOT® standard design)
Unit Design
"Mounting close
to motor" design
with option P2.A The following illustration shows an example of the MOVIMOT
®
inverter with option P2.A
mounted close to the motor with corresponding nameplate and unit designation:
52232AXX
MM22C-503-00/0/P22A/REZA/ALA4
Plug connector for the connection to the motor
Terminal box design
Adapter for mounting close to the motor
21 = Size 1
22 = Size 2
Circuit type
0 =
ᛴ
1 =
Ħ
MOVIMOT
®
