Page 53: Description of the dip switches s1
Operating Instructions – MOVIMOT® MM03C - MM3XC
53
7
Description of the DIP switches S1
Startup of Standard Design
7.3
Description of the DIP switches S1
DIP switches
S1/1-S1/4
Selection of RS-485 address of MOVIMOT
®
via binary coding
Depending on the control of MOVIMOT
®
, different addresses must be set:
DIP switches
S1/5
Motor protection activated or deactivated
•
If the MOVIMOT
®
inverter is mounted close to the motor (with option P2.A or in the
field distributor), the motor protection must be deactivated.
•
To ensure motor protection after all, a TH (bimetallic thermostat) must be used. In
this case, the TH opens the sensor circuit after reaching the nominal response tem-
perature (see the "Startup with field distributor" section in the "Drive System for De-
centralized Installation" system manual).
Decimal
Address
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
S1/1
–
X
–
X
–
X
–
X
–
X
–
X
–
X
–
X
S1/2
–
–
X
X
–
–
X
X
–
–
X
X
–
–
X
X
S1/3
–
–
–
–
X
X
X
X
–
–
–
–
X
X
X
X
S1/4
–
–
–
–
–
–
–
–
X
X
X
X
X
X
X
X
X
= ON
–
=
OFF
Control
RS-485 address
Binary control (terminal operation)
0
Via external AS-i binary slave (MLK11A)
0
Via keypad (MLG.., MBG..)
1
Via fieldbus interface (MF..)
1
Via fieldbus interface with integrated small control system (MQ..)
1 to 15
Via RS-485 master
1 to 15
0
