Page 117: 9startup with communications interface / fieldbus
Operating Instructions – MOVIMOT® MM03C - MM3XC
117
9
Startup procedure
Startup with Communications Interface / Fieldbus
9
Startup with Communications Interface / Fieldbus
9.1
Startup procedure
1. Review correct connection of MOVIMOT
®
(see the section "Electrical Installa-
tion").
2. Set the correct RS-485 address on DIP switches S1/1...S1/4. Always set address
"1" in conjunction with SEW fieldbus interfaces (MF...).
3. Set the minimum frequency f
min
with switch f2.
4. If ramp is not set via fieldbus, set ramp time with switch t1 (ramp times are based on
a setpoint jump of 50 Hz).
5. Check whether the required direction of rotation is enabled.
Decimal
address
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
S1/1
–
X
–
X
–
X
–
X
–
X
–
X
–
X
–
X
S1/2
–
–
X
X
–
–
X
X
–
–
X
X
–
–
X
X
S1/3
–
–
–
–
X
X
X
X
–
–
–
–
X
X
X
X
S1/4
–
–
–
–
–
–
–
–
X
X
X
X
X
X
X
X
X
= ON
–
=
OFF
Switch f2
Detent position
0
1
2
3
4
5
6
7
8
9
10
Minimum frequency f
min
[Hz]
2
5
7
10
12
15
20
25
30
35
40
Switch t1
Detent position
0
1
2
3
4
5
6
7
8
9
10
Ramp time t1 [s]
0.1
0.2
0.3
0.5
0.7
1
2
3
5
7
10
Terminal R
Terminal L
Message
Activated
Activated
•
Both directions of rotation are enabled
Activated
Not activated
•
Only clockwise direction of rotation is enabled
•
Preselected setpoints for counterclockwise rotation result in
standstill of drive
Not activated
Activated
•
Only counterclockwise direction of rotation is enabled
•
Setpoint selections for clockwise lead to the drive being
stopped
Not activated
Not activated
•
Unit is blocked or the drive is stopped
3
4
5
6
7
8
3
4
5
6
7
8
24V
R
L
24V
R
L
24V
R
L
24V
R
L
0
0
I
