Operating Instructions – MOVIMOT® MM03C - MM3XC
43
6
Connection of MOVIMOT® MM../AZSK (connection option B)
Electrical Installation with Integrated AS-Interface
6.4
Connection of MOVIMOT
®
MM../AZSK (connection option B)
The following figure shows the connection of the MM../AZSK design.
52061AXX
AZSK plug connector
[1] M12 plug connector
(plug, black)
1
24 V
24 V supply (AUX-PWR)
2
N.C.
Not assigned
3
0 V
AUX-PWR reference potential
4
N.C.
Not assigned
[2] M12 plug connector
(plug, yellow)
1
AS-i +
AS-i data cable +
2
0 V
AUX-PWR reference potential
3
AS-i -
AS-i data cable -
4
24 V
24 V supply (AUX-PWR)
[3] M12 plug connector
(socket, black)
1
VO24
24 V voltage supply for sensors
2
DI3
Sensor input DI3
3
VO
⊥
0 V reference potential for sensors
4
DI2
Sensor input DI2
M
3~
L1
L2
L3
PE
K11
F11/F12/F13
13
14
15
L1
L2
L3
BMG
RD
WH
BMG
BL
BW.
4
2
1
3
3
1
4
2
24V
4
2
1
3
4
2
1
3
3
1
4
2
AS-I+
AS-I - 24 V
DI3
VO24
3
1
4
2
DI2
[1]
[2]
[3]
BK
YE
BK
VO
MM../AZSK
