Operating Instructions – MOVIMOT® MM03C - MM3XC
7
Description of the DIP switches S2
Startup of Standard Design
Setting bit 8 in the control word allows the brake to be released under the following con-
ditions:
Setpoint selection
in terminal opera-
tion
Setpoint selection in terminal operation depends on status of terminal f1/f2:
Behavior with a
non-operating unit
In case of a non-operating unit, the brake is always applied independent of the setting
of terminal f1/f2 or bit 8 in the control word.
LED display
The yellow LED display flashes periodically and quickly (t
on
: t
off
= 100 ms : 300 ms) if
the brake was released for manual procedure. This applies to terminal operation as well
as bus operation.
Basic control block
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Control word
Not assigned
Bit
"8"
"1" =
Reset
Not assigned
"1 1 0" = Release
otherwise stop
Virtual terminals for releasing the brake without
drive enable
Enable
condition
Fault condition
Status of bit 8 in con-
trol word
Brake function
Unit
enabled
No unit fault /
no communications timeout
"0"
Brake is controlled by
MOVIMOT
®
Unit
enabled
No unit fault /
no communications timeout
"1"
Brake is controlled by
MOVIMOT
®
Unit not
enabled
No unit fault /
no communications timeout
"0"
Brake closed
Unit not
enabled
No unit fault /
no communications timeout
"1"
Brake released for man-
ual procedure
Unit not
enabled
Unit fault /
communications timeout
"1" or "0"
Brake closed
In case of a unit fault / communications timeout, the brake cannot be released via
special function.
Enable condition
Terminal f1/f2
Active setpoint
Unit enabled
Terminal f1/f2 = "0"
Setpoint potentiometer f1 active
Unit enabled
Terminal f1/f2 = "1"
Setpoint potentiometer f2 active
0
0
I
