Rockwell Automation 1760-xxxx Pico GFX-70 Controllers User Manual User Manual
Page 97

Publication 1760-UM002B-EN-P - March 2005
Commissioning 3-19
1.
Change to the Status display and press the ESC button.
The cursor changes to the display of the network station NT.. and
flashes. The station number is displayed in front of the inputs and
outputs.
2.
Change the number of the required station using the up/down arrow
keys.
3.
Press the OK button.
4.
If you want to view the state of the inputs and outputs of a local
expansion, press the OK button.
If you press the ESC button again or the OK button, the display of the
input and output states of the station is terminated.
1I12..........
I NT1
P-
MO 06:42
1Q1.......
RUN
3I12.....7....
I NT3
P-
MO 06:42
3Q1.3..6..
RUN
3R12.....7....
I NT3 DC P-
MO 06:45
3S1.3..6..
RUN
IMPORTANT
The station showing the status on its display cannot
read its own data from the network.
Example: NT3 flashes on station 3. The inputs and
outputs 3I.., 3R.., 3Q.. and 3S.. cannot be displayed.
If the NT3 display is not flashing, the inputs and
outputs are shown.
