Pico GFX-70 Settings 7-19
Deactivation of Card Mode
1. Select
CARD MODE
✓ .
2. Press OK.
The RUN mode function is deactivated.
The Pico GFX-70 default setting is for display of the CARD MODE menu,
i.e. Pico GFX-70 starts in RUN mode without the memory module when the
power is switched on.
Terminal Mode
The Pico GFX-70 also supports the TERMINAL MODE. Terminal mode
enables the display and the keypad of the GFX to be used as a terminal for
operating another device. In this operating mode you are thus able to remotely
control all devices supporting Terminal mode operation. The interface to the
other device can be implemented using the serial interface or the Pico-Link.
Permanent TERMINAL MODE Setting
In the SYSTEM menu you set the GFX to start in TERMINAL MODE when
the power supply is switched on.
Switch to the System menu.
DEBOUNCE
✓ ▲
P BUTTONS
RUN MODE
✓
CARD MODE
▼
IMPORTANT
TERMINAL MODE operation is only possible if the GFX
is in STOP mode.
IMPORTANT
If Pico GFX-70 is protected by a password, the System
menu will not be available until Pico GFX-70 is “unlocked”
(see Unlocking Pico GFX-70 on page 7-5).
